    40 AWG Airport Security X Ray baggage scanner to check luggage security

    Ask Lasest Price
    Brand Name : SECUSCAN
    Model Number : AT6550
    Certification : CE, ISO9001, India-AERB, US.FDA
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 300 sets/month
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    40 AWG Airport Security X Ray baggage scanner to check luggage security

    40AWG Airport Security X Ray baggage scanner to check luggage security


    Quick Details

    General Specification:

    Tunnel Size:650(W)*500(H)mm
    Conveyor Speed:0.22m/s
    Conveyor Max Load:170kg
    Wire Resolution:40AWG

    Spatial resolution:

    horizontal:1.3 or 1.0mm, vertical: 1.3 or 1.0mm
    Penetration:30 to 40mm Steel
    Film Safety:Guarantee ISO1600 Film
    X-ray Leakage:<1 μSv/h (at a distance of 5cm
    from external housing)
    Pass rate:720 bags per hour

    Installation Data:

    Operation temperature/Humidity:

    0℃-45℃/20%-95%(non-condensing)
    Storage Temperature/Humidity:-20℃-60℃/20%-95%(non-condensing)
    Operation Power:187~240VAC, 50/60Hz
    Power Consumption:
    1.0 KW (max), 0.7KW(working)
    Noise:<58db

    X-ray Generator:

    Beam direction: DiagonalDiagonal

    Generate angle:

    80 degree
    Anode Voltage:140Kv or (100Kv to 160Kv adjustable)
    Anode power:0.4 to 0.5mA
    Cooling / Duty Cycle:Oil Cooling /100%

    Image System

    X-ray Sensor:L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
    Monitor:High Resolution Color, LCD Accord, 17 inch
    (19 inch optional)
    Image processing:

    Edge enhancement, image strengthening, image lightening

    , reducing darkening, image returning,image, retrieval.

    Image Grey Level:4096
    Image Processing:24bit for processing real time
    Image storage:Storage 100,000 pictures in real time
    Zoom:max 64 Times Enlarge, Whole screen continuous observation

    Assist of detecting organic and inorganic items such as
    weapons, explosives and narcotics using different colour show.

    New appearance for high performance AT6550B:


    40 AWG Airport Security X Ray baggage scanner to check luggage security

    Company Information"

    We are the factory of security equipment with 8 years experience in China, which specialized on

    • X Ray Baggage Inspection Scanner ,
    • Under Vehicle Inspection System
    • Hand Held Metal Detector,
    • Walk Through Metal Detector ,
    • bottle liquid scanner,
    • Explosive Trace Detctor
