Small tunnel size dual energy Baggage And Parcel Inspection machine for Police security check SPX-5030C

SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Small tunnel size dual energy Baggage And Parcel Inspection machine for Police security check SPX-5030C from wholesalers

    Buy cheap Small tunnel size dual energy Baggage And Parcel Inspection machine for Police security check SPX-5030C from wholesalers
    • Buy cheap Small tunnel size dual energy Baggage And Parcel Inspection machine for Police security check SPX-5030C from wholesalers
    • Buy cheap Small tunnel size dual energy Baggage And Parcel Inspection machine for Police security check SPX-5030C from wholesalers
    • Buy cheap Small tunnel size dual energy Baggage And Parcel Inspection machine for Police security check SPX-5030C from wholesalers

    Small tunnel size dual energy Baggage And Parcel Inspection machine for Police security check SPX-5030C

    Ask Lasest Price
    Brand Name : SECUPLUS
    Model Number : SPX-5030C
    Certification : CE, ISO
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 1000 sets/year
    Delivery Time : 5-7 working days after confirming the order
    • Product Details
    • Company Profile

    Small tunnel size dual energy Baggage And Parcel Inspection machine for Police security check SPX-5030C

    Small tunnel size Window XP Baggage And Parcel Inspection machine for Police security check SPX-5030C


    General Specification

    Tunnel Size:

    500(W)*300H)mm

    Conveyor Speed:

    0.22m/s

    Conveyor Max Load:

    150kgs

    Wire Resolution:

    32AWG to 38 AWG

    Spatial resolution:

    horizontal:1.3 or 1.0mm,
    vertical: 1.3 or 1.0mm

    Penetration:

    27-32mm Steel

    Film Safety:

    Guarantee ISO1600 Film

    X-ray Leakage:

    <1μGy/h (at a distance of 5cm From external housing)

    Pass rate:720 bags per hour

    Beam direction:

    Diagonal

    Generate angle:

    80 degree

    Anode Voltage:

    140Kv

    Anode power:

    0.4 to 1.2mA

    Cooling / Duty Cycle:

    Oil Cooling /100%

    X-ray Sensor:

    L-Shaped Photodiode Array (mono-energetic), 12bit Deep

    Monitor:

    High Resolution LCD Accord, 17 inch

    Image Processing:

    Edge enhancement, image strengthening, image lightening,

    reducing darkening, image returning, image retrieval.

    Image Grey Level:

    4096

    Image Max Resolution:

    1024 * 768 pixel

    Image Processing:

    24bit for processing real time

    Image storage:

    Storage 100000 pictures in real time

    Zoom:

    64 Times Enlarge, Whole screen continuous observation

    Operation temperature/Humidity:

    0℃-45℃/20%-95%(non-condensing)

    Storage Temperature/Humidity:

    -20℃-60℃/20%-95%(non-condensing)

    Operation Power:

    220VAC(±10%)50±3Hz

    Power Consumption:

    1 KW (max)

    Noise:

    <60db

    1. The SECUSCAN X Ray Baggage Scanner offers another way to see inside of handbags,briefcases. It popular accepted as a nonintrusively optimize security measure .
    2. AT5030A give you innovative and costeffective solutions. It¡s a great help to exclude the threats and contraband.
    3. AT5030A is friendly operation system, and easy to maintenance .
    4. SECUSCAN is together with you to antiterrorism


    Applications:

    01. railway station
    02. Transport terminals,
    03. Buildings,
    04. Factories (to find needle in clothing, shoes, bags),
    05. Courthouses,
    06. Embassies,
    07. Military installations,
    08. Prisons,
    09. Hotels,
    10. Schools ,
    11. Convention centers,
    12. Security checkpoints
    13. Special events location


    Our Work Shop


    Detailed Product Description:

    • SECUPLUS X RAY SYSTEM offers a modern technology to secure entry checkpoints for important locations like airports, transport terminals, buildings, and so on.
    • Our systems screen baggage and parcel, to detect contraband, weapons, dangerous and illegal items. Model AT100100 easily accommodates the inspection of big size baggage and parcels.
    • SECUPLUS X RAY SYSTEM is based on user-friendly design with ergonomic operator control panel and adjustable control panel stand. It is easy to installation and maintenance. Over 100 systems per month installed in china and abroad.
    • SECUPLUS branded products received certifications of CE, Test report from China Ministry of Public Security and Copyright for image Operation software SPHOTO.
    • As a manufacturer SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LTD has gotten the certificate ISO CE ROHS FCC certified company. We have Radiation Safety license from China Environmental Protection Administration
    • SECUPLUS X RAY SYSTEM is a professional security solution provider, a wise choice to governments and partners.

    Company Profile


    A good supplier will save you money and be free from trouble.
    Quality means a lot for a security products wholesaler like you.
    To be safe from customer complaints, you may need a very reliable supplier to count on.
    SECUPLUS has already 13 years professional experience in
    • X ray Baggage Scanner
    • Walk Through Metal Detector
    • Under Vehicle Surveillance System
    • Hand Held Metal Detector
    • Explosives Trace Detection
    • Dangerous Liquid Scanner
    We would very much welcom your enquiry, surely you will get our best price.
    Our service
    1. All products purchased in our company are guaranteed to keep in good repair for one year.
    2. If quality problems happen in guarantee period, our company will maintain for free.
    3. Additionally, our company provides technical support and fittings for life.
    4. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.
    5. If you are caught in some problems when using our products, welcome to contact us at any time.
