    38mm Steel Penetration X-ray Security Screening Equipment Oil Cooling

    Ask Lasest Price
    Model Number : AT8065
    Brand Name : SECUSCAN
    Certification : CE, ISO
    Delivery Time : One week when there is stock, One month when no stock.
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 300 sets/month
    Price : Negotiable
    • Product Details
    • Company Profile

    38mm Steel Penetration X-ray Security Screening Equipment Oil Cooling

    38mm Steel Penetration X-ray Security Screening Equipment Oil Cooling


    SECU SCAN service:

    • Free training in factory
    • Life time technic support
    • After-sales service calling in 24 hours
    • 72 hours give you the solution for maintenance
    • Manufacturer authorization to protect you in the project
    • OEM and ODM service accept

    Company information:


    When your operation must be economical,compliant and, above all, effective, you need a proven partner that is driven by innovation and backed-by professional support team.


    A partner like SECUSCAN systems as the biggest manufacturer of security inspection system in south of China.


    Specifications:


    Tunnel Size:

    800(W)*650(H)mm

    Conveyor Speed:

    0.22m/s

    Conveyor Max Load:

    200kgs

    Dose per Inspection:

    <1.6 μGy/h

    Resolution:

    <0.101mm Metal Wire

    Penetration:

    30mm Steel, 38mm steel guarantee

    Film Safety:

    Guarantee ISO1600 Film

    X-ray Leakage:

    <0.1 μGy/h (at a distance of 5cm From external housing)

    Generate direct:

    Downward

    Generate angle:

    80 degree

    Anode Voltage:

    100-160Kv

    Anode power:

    0.4 to 1.2mA

    Cooling / Duty Cycle:

    Oil Cooling /100%

    X-ray Sensor:

    L-Shaped Photodiode Array (mono-energetic), 12bit Deep

    Monitor:

    High Resolution Color, LCD Accord, 17 inch

    Image Processing:

    Edge enhancement, image strengthening, image lightening, ]reducing darkening, image returning, image retrieval.

    Image Grey Level:

    4096

    Image Max Resolution:

    1024 * 1280 pixel

    Image Processing:

    24bit for processing real time

    Image storage:

    Storage 60000 pictures in real time

    Zones & Zoom:

    1-9 Image regions, 2, 4, 8, 16 Times Enlarge,

    Whole screen continuous observation

    Operation temperature/Humidity:

    0℃-45℃/20%-95%(non-condensing)

    Storage Temperature/Humidity:

    -20℃-60℃/20%-95%(non-condensing)

    Operation Power:

    220VAC(±10%)50±3Hz

    Power Consumption:

    1.2 KW (max), 0.3KW(working)

    Noise:

    <58db


    Packing size:


    Plywood package, one unit in two packages

    Scanner packing size: 215*125*179cm

    Console packing size: 115*92*142cm
