Luggage X-ray Inpsection Machine SPX8065 X ray Baggage SCanner for
Station
General Specification :
Tunnel Size: 800mm×650mm
Conveyor Speed: 0.22m/s
Conveyor height : 338.5mm
Conveyor Max Load:200kg
X ray Dose per inspection <0.1.25μSv
Wire Resolution:38AWG Guarantee 40 AWG typical
Spatial resolution Level: dia1.3mm,Vertical: dia1.3mm
Penetration: 30 mm steel guarantee, 32mm steel typical
Penetration Resolution :30AWG guarantee, 32AWG typical
Film Safety :Guarantee ASA/ISO1600 Film
X-ray Leakage: <0.5 μSv/h (at a distance of 5cm From external
housing)
Image System :
Technical Principle: Dual-energy X-ray Imaging;
X-ray Sensor: L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
Monitor: High Resolution Color, LCD Accord, 17inch
Image Display: High resolution of 1024 * 1280 pixel; Image Grey Level: 65536
Image Enhancement: 1-64times enlargement continuity, Color/BW, negative, high/low
penetration, organic /inorganic Stripping, general enhancement, and
pseudo color, etc.
Image Recall: All preceding images recallable, retrieval.
Explosives & Narcotics Detection: Explosives & narcotics alarm and
highlight according to atomic number
signature
High Density Region Alarm: Impenetrable region alarm and highlight, for possible concealing
of threats and contrabands
Threat Image Projection: Inserting fictional, but realistic images of threat items into
baggage during screening operation, for maintenance of vigilance,
as well as training and assessment of image identification
capability
Image Archive: Up to 100,000 images stored automatically, enable transferring to
USB disk, and converting to JPG, BMP and other general formats
Miscellaneous Functions : Time/date display, counters, user management, system-on/X-ray-on
timers, power on self test, built-in diagnostic facilities,
dual-direction scanning, system log,
system standby and stimulant training, ADS etc.
Network Applications: Multiple remote applications available based on Ethernet LAN and
windows platform, such as image centralized storage and identify,
recheck workstation, and network TIP, etc ( Optional) .
Images process: 24bit real time processing ,4colors analysis, Images displayed
marked date and
ID NO ,Count the number of bags.
Memory gray level: 65536
| X-ray Sensor | L-Shaped Photodiode Array (multi-energetic) , 12bit Deep |
| Monitor | High Resolution Color, LCD Accord, 17 or 19inch |
| Image Grey Level | 4096 |
| Image Max Resolution | 1024 * 1280 pixel |
| Image Processing | 24bit for processing real time |
Operating Environment:
Operation temperature/Humidity:5℃-40℃/10%-95%(non-condensing)
Storage Temperature/Humidity: -20℃to 60℃/ 5%-95%(non-condensing)
Operation Power: 220VAC(±10%)50±3Hz (Optional: 100VAC,110VAC,120VAC,200VAC)
Power Consumption: 1.0KW (max), 0.7KW(working)
Noise: <58db
Dimensions (L×W×H): 2848.5mm x1095mm x1535.5 mm
Device Weight: 680Kg
G.Weight: 900Kg
Packing Volume: 6.63CBM
Computer Character:
CASE: IPC7132
Power: 250W/ATX
Main board: AIMB 501G2
CPU: G1610 2.6G
Storage: 2GB 1600MHz DDR3 Innodisk
Hard Disk: SEAGATE 500G 3.5”
X-ray Generator:
Anode Voltage: 140kv
Anode power: 0.3mA
Generate angle: 80 degree upward
Brand: own made
Generate direct: from top to bottom
Cooling / Duty Cycle: Oil Cooling /100%
Other Characters:
Detect PCB board: UK brand Sensortech
Extension Rollers: customize size length
Support card reader operator access
CD DVR/RW unit: Optional
Computer system: XP system
Monitor: 17 inch DELL two monitors
