Stock Baggage X-ray Scanner for Factory parcel inspection SPX5030C
SECUPLUS
General Specification
Tunnel Size: | 500(W)*300H)mm |
Conveyor Speed: | 0.22m/s |
Conveyor Max Load: | 150kgs |
Wire Resolution: | 32AWG to 38 AWG |
Spatial resolution: | horizontal:1.3 or 1.0mm,
vertical: 1.3 or 1.0mm |
Penetration: | 28-32 mm Steel |
Film Safety: | Guarantee ISO1600 Film |
X-ray Leakage: | <1μGy/h (at a distance of 5cm From external housing) |
| Pass rate: | 720 bags per hour |
Beam direction: | Diagonal |
Generate angle: | 80 degree |
Anode Voltage: | 140Kv |
Anode power: | 0.4 to 1.2mA |
Cooling / Duty Cycle: | Oil Cooling /100% |
X-ray Sensor: | L-Shaped Photodiode Array (mono-energetic), 12bit Deep |
Monitor: | High Resolution LCD Accord, 17 inch |
Image Processing: | Edge enhancement, image strengthening, image lightening, reducing darkening, image returning, image retrieval. |
Image Grey Level: | 4096 |
Image Max Resolution: | 1024 * 768 pixel |
Image Processing: | 24bit for processing real time |
Image storage: | Storage 100000 pictures in real time |
Zoom: | 64 Times Enlarge, Whole screen continuous observation |
Operation temperature/Humidity: | 0℃-45℃/20%-95%(non-condensing) |
Storage Temperature/Humidity: | -20℃-60℃/20%-95%(non-condensing) |
Operation Power: | 220VAC(±10%)50±3Hz |
Power Consumption: | 1 KW (max) |
Noise: | <60db |
The SECUPLUS X Ray Baggage Scanner offers another way to see inside
of handbags,briefcases. It popular accepted as a nonintrusively
optimize security measure .
SPX5030C give you innovative and costeffective solutions. It's a
great help to exclude the threats and contraband.
SPX5030C is friendly operation system, and easy to maintenance .
SECUPLUS is together with you to antiterrorism
Applications:
01. railway station
02. Transport terminals,
03. Buildings,
04. Factories (to find needle in clothing, shoes, bags),
05. Courthouses,
06. Embassies,
07. Military installations,
08. Prisons,
09. Hotels,
10. Schools ,
11. Convention centers,
12. Security checkpoints
13. Special events location
Related products
Detailed Product Description:
1 SECU PLUS offers a modern technology to secure entry checkpoints
for important locations like airports, transport terminals,
buildings, and so on.
2 Our systems screen baggage and parcel, to detect contraband,
weapons, dangerous and illegal items. Model SPX100100 easily
accommodates the inspection of big size baggage and parcels.
3 SECU PLUS is based on user-friendly design with ergonomic
operator control panel and adjustable control panel stand. It is
easy to installation and maintenance. Over 100 systems per month
installed in china and abroad.
4 SECU PLUS branded products received certifications of CE, Test
report from China Ministry of Public Security and Copyright for
image Operation software SPHOTO.
As a manufacturer SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LTD
has gotten the certificate ISO, CE, FCC, ROHS certified company. We
have Radiation Safety license from China Environmental Protection
Administration.
SECU PLUS X-ray Scanner is a professional security solution
provider, a wise choice to governments and partners.
Our Company Profile
Our company established since 2003, and specialized in security
equipments more than 10 years.
Our main products:
X ray baggage scanner
Walk through metal detector
Under vehicle surveillance system
Explosives/drug detector
Dangerous Liquid scanner
We would very much welcom your enquiry, surely you will get our
best price.
